PCB Design Services

We are experts in PCB layout with a solid reputation in RF systems, high speed digital, mixed-signal and EMC analog. We design single, double and multi-layer boards(from 1 to 40 layers), Rigid and Flex-Rigid printed circuit boards. Even if your project entails high speed constraint-driven requirements, routing or basic I/O, our engineers and technical staff have the expertise to deliver comprehensive designs which are top quality, well-managed and on-time.

We have extensive experience in creating RoHS compliant designs for new layouts and conversions of existing assemblies. Meanwhile, the capability of our reverse engineering, which we can convert an existing board assembly into a complete and functional database without any documentation.

Capabilities and Services offered:
    •  Schematic capture
    •  Assembly drawings, fabrication drawings
    •  Board layout from a customer supplied schematic diagram
    •  Reverse engineering
    •  Controlled impedance (single and differential) designs
    •  Layout for RF designs
    •  High Speed Backplane and Mid-plane DesignsMicro BGA / Micro via/ Blind & Buried Vias
    •  Multi-layer boards, split ground planes, differential pairs, high speed rules
    •  Routing per trace/space, keep-out, and clearance rules specified by customer
    •  Component resequencing based on physical layout, reverse annotation to schematic
    •  DFT audit, test point placement, test probe clearance per customer rules, testability report
    •  Surface mount or through hole designs

    •  Unusual PCB shapes

    •  Any other customer specified outputs.
