Fabrication Capabilities

Shenzhen Grande Electronic offers Printed Circuit Board manufacturing, providing high quality and compitive price of Printed Circuit Boards(PCB).  No matter it is a single board for a prototype or large volume production runs, Grande also can come to meet your PCB fabrication needs in a variety of materials and technologies.  We focus on multi-layer printed circuit boards, impedance Controlled circuit boards and HDI PCBs in varying complexities.  If you are interested in it ,you can send an inquiry.  Welcome to contact us !

Technical Capability:
    •  Layers: 1-30 layers
    •  Max Size: 650*1100mm
    •  Min line Width/Space: 3/3 mil
    •  Min Hole Size: 4 mil
    •  Max copper thinkness : 7oz

PCB Materials:
    •  FR-4
    •  High TG FR-4
    •  PTFE
    •  Aluminum Base
    •  Rogers
    •  Specialized material per your request

Solder Mask:
Green, Yellow, Black, Red, Blue and  and other color you required.

Final Finishes:
HASL,  Immersion Gold, Gold Plating, Immersion Silver, Immersion Tin, OSP and etc.

Inspection Methods:
100% Visual inspection, Electrical testing , Flying probe or Nails Bed, Sample lot inspection, Cross sectioning.

Delivery:
Fast Prototype : 24 Hours
Standard Prototype: 3-7days
