How do I start PCB designing?

Time:2019-07-12 17:11:07 Click:

When it comes to the start of PCB Designing,



 1. Mastering a certain hardware design capabilities and understanding the product function requirements;

 2. Obtaining the Schematic (including selection of components);

 3. Choosing EDA design tools for PCB file design;

 4. Work up the complete product engineering files ( Such as PCB/Gerber file, BOM list, etc);
