What Is PCB Prototype?

Time:2021-01-15 11:44:58 Click:

What is PCB prototype?



PCB prototype refers to the trial production of circuit board before mass production. It is a way to check whether PCB circuit design is reasonable and function is normal or not. At present, a great number of pcb manufacturers whom provide PCB prototype services that have stable customers and are very popular in the market.





PCB Prototype Service Range

1. FR4 board;

2. Aluminum board;

3. Ceramic board;

4. FPC board;

5. Rigid-flex board, etc.









Why need PCB prototype?



1. To save cost



The obvious advantage of PCB prototype is that it can help companies save costs, because through PCB trial production and professional testing, you can find out whether there are problems with the circuit design, thereby avoiding large-scale production without the need for testing and economic losses caused by poor preservation.



2. To optimize PCB design



How to etch circuits on the PCB and achieve higher efficiency is related to PCB circuit design. Through PCB prototype (sample board production), relevant manufacturers can continuously improve circuit design during testing, which is able to help companies further optimize circuit design and improve PCB board efficiency. Furthermore, PCB prototype will also greatly help improve the company's product quality and corporate reputation.









3. To bring the technological breakthroughs possibility for innovative companies



Although plenty of innovative R&D circuit design companies have achieved a lot achievements in R&D capabilities, they still need entrust some professional companies to complete the prototype work. By signing a long-term cooperation agreement, we can continuously verify the rationality of the circuit design through PCB prototype, thereby improving the company's overall innovation capability and laying a good foundation for the company to further break through the technical bottleneck.



Therefore, based on the above points, PCB prototype has now become an indispensable service for every PCB manufacturer. Because the function of PCB prototype cannot be underestimated, whether it is to help other companies save costs, help companies improve designs, or lay the foundation for the company's R&D breakthroughs, etc. In a nutshell, PCB prototype is indispensable in products innovation and development.
